Both system utilize an easily removable inboard plumbing module, no need to have a motor out on the skid.

 In good news we’ve ran about 15,000 acres in the last 5 days and not one problem with the spray system!   It makes these long days easier when you aren’t fighting equipment.

A sneak peek at our new lightweight composite spray system front end, stay tuned for more information...…...

The mould that will be used to create our carbon fiber R44 spray tanks is finished. We are excited to have this major piece of the puzzle completed, now we can start making tanks!

Our R44 spray tank mold being created by 5 axis CNC routing of high density fiber board that will then be overlayed with fibre glass, this mold will be good for approx 30 tanks during which time we will make a permanent mold.

Our second generation R66 spray system will be avialable to order May/June 2018, features are:

• Carbon fiber tank and boom support arms.
• Jettison door with 80% evacuation in 4.5 seconds.
• Light weight and durable carbon booms.
• Easily removable carbon booms with forward facing stowage for ferrying.
• Operator configurable pump/plumbing modules.
• Snug belly fit.
• Aerodynamic design with inboard motor.
• System can be ordered with petrol or an electric pump.
• STC comes standard with flow rate controller and boom isolate.

Our brand new R44 spray system will be available early next year, features are as follows:
• Carbon fiber tank and boom support arms.
• Jettison door with 80% evacuation in 4.5 seconds.
• Light weight and durable carbon booms.
• Easily removable carbon booms with forward facing stowage for ferrying.
• Operator configurable pump/plumbing modules.
• Snug belly fit.
• Aerodynamic design with inboard motor.
• R44 Tank shape allows the engine heat to escape.
• System can be ordered with petrol or an electric pump.
• STC comes standard with flow rate controller and boom isolate

Many thanks to Helicrops LLC for providing their R66 fitted with our spray system for display purposes.

Here is the prototype of our one piece pump/plumbing/control module for the new R66/R44 gear. Seen here in front of a Gen 1 R66 system with stainless front end.
Features:
Honda wx15motor with remote fuel tank
Keene p90 pump
Intake vacuum pulse driven accessory fuel pump
Remote throttle and shutoff
Agnav flow controller
Agnav recirc valve with integral adjustable boom suckback
Dual boom feed for optional boom isolate

We received a great recommendation today from Ed at Wyoming Helicopters whom have been using our R66 system for quite some time:
"So this year we sprayed 80,000 acres ULV of mosquitoes and 15,000 of conventional weed spray mostly 3 gallon work. System worked flawlessly.
